Close Up Lens Considerations

Roundleaf Sundew (Drosera Rotundifolia) Eaing a Fly ©Mike Spinak

Most lens manufacturers offer 50 mm or so close-up lenses, ~100 mm close-up lenses, and ~180 close-up lenses. Photographers who are new to this specialized field may not know how or why to choose among them. Life-size is life size, right?

Yes, life size is life size, but there are still significant differences between close-up lenses.

The most readily apparent differences between these three categories are cost, size, and weight. The 50-60 mm close-up lenses are smaller, lighter, and less expensive than the 85-105 mm ones, which are, again, smaller, lighter, and less expensive than the 150-200 mm ones. These differences can be nearly two pounds, and well over a thousand dollars. Cost and easy carrying can be overriding criteria for some, and smaller macro lenses can be perfectly sufficient.

If size, weight, and cost were the whole story, then everyone would be using the shortest close-up lenses they can. So, longer focal length close-up lenses obviously have some pretty compelling advantages, too, right?

One potential advantage, for some compositions, is that longer focal length lenses have a narrower angle of view than shorter focal length lenses. While a honey bee photographed at life size will be the same size on film (or sensor) whether snapped with a 50 mm lens or a 180 mm lens, the 50 mm lens will show a much wider sweep of the bee’s background than 180 mm lens will. The longer lens’s narrower angle of view “isolates” the subject more than the shorter lens’s broader angle of view. Since many photographers don’t like to include extraneous details in their compositions, they often prefer longer close-up lenses for their facility at singling the main subject out from any distractions in the background.

Another point that sometimes favors longer close-up lenses is greater working distance. A 50 mm close-up lens will need to be about 9.5 inches from the subject to the film/sensor plane in order to shoot the subject at life size, a 100 mm will need about a foot, while a 180 mm close-up lens will need to be about 19.5 inches from the subject to the film plane in order to shoot it at life-size. It is much easier to avoid scaring away (or enraging) small creatures from 19.5 inches than from 9.5 inches, making it preferable to photograph skittish or cantankerous small animals with longer focal length close-up lenses. (On the other hand, if you are trying to photograph a waist-high wildflower from the top down, a 50 mm or 100 mm close-up lens will be preferable, since you can only shoot from so high, without needing a step-ladder to stand on. Which focal length close-up lens will serve you best depends on the subject, angle, and what you are trying to do.)

Besides the issue of alarming small creatures, greater working distance also makes lighting easier to deal with. A 1:1 shot with a short close-up lens could require you to get so close that your camera gear (or your body) blocks the natural light from your subject. The greater distance with longer close-up lenses prevents this. Similarly, this greater working distance allows you to easily use a regular flash with longer close-up lenses. A normal flash head can be difficult to use with the short working distance of smaller close-up lenses, which may make a special close-up ring flash (which attaches around the front of your lens) necessary.

A final advantage of the longest close-up lenses is that they come fitted with lens collars. A lens collar is a ring shaped clamp around your lens, with a “foot” jutting from the bottom. The clamp holds the lens, and the foot attaches to the tripod. By shifting the area where the tripod couples with the camera system from the bottom of the camera body to the foot of the lens collar, the camera system can be supported from a more neutrally balanced point. This minimizes camera-system movement from instability. It also lessens stress upon the lens mount (the area of the camera body where it locks to the lens). Lens collars also have a couple other significant advantages for close-up photographers, beyond shifting system support forward of the camera body. The first is that the lens collar’s ability to be loosened allows for rotating the camera from horizontal to vertical (or back, or anywhere in between) in a quick, easy manner, while the distance, angle, and center of the picture are maintained. Other methods of shifting between vertical and horizontal require dismounting the camera, and/or adjusting the tripod, and then recomposing from scratch–which is a more involved and more time-consuming process.

The second other advantage of lens collars is that (when the lens collar’s foot has a quick-release plate attached, and the tripod’s head has a quick-release clamp attached) they allow easily moving the camera and lens forward in minute increments while maintaining the same composition, without needing to move the tripod forward, readjust the tripod and the tripod head, and recompose. A lens collar’s increased facility with isolated forward/backward adjustments, and with isolated vertical/horizontal rotation adjustments, is especially helpful with extreme close-up photography, where the set-up often needs to be exacting to within millimeters, in multiple dimensions, in order for the composition to work.

So far, optical quality considerations haven’t been discussed. Usually, these considerations (“Which is sharpest?”, etc.) are foremost in photographers minds when making lens decisions. While there are minor differences (the longest close-up lenses tend to be best, the shortest tend to be second best, and the middle lengths tend to be third), choosing a close-up lens is a rare case where optical considerations are best kept secondary to other factors. All close-up lenses tend to be optically superb, and among the most highly corrected (for field curvature, barrel or pincushion distortion, and chromatic aberration) kinds of lenses, regardless of focal length or manufacturer. Angle of view, working distance, and lens collar, are generally more germane.

A final factor to consider when choosing a close-up lens is how else you will be using the lens. These lenses can be used for more than just close-up work; they make great lenses for subjects at greater distances, too. Many professionals and serious amateurs get dedicated close-up lenses, and do not factor other uses into their close-up lens choice, but most cannot afford that luxury. Double use becomes an important point. So which are best for more general photography? That is entirely dependent upon the subjects you like to shoot, your style, and personal taste. Generally speaking, more people find the shorter and middle focal length close-up lenses better for general use than the longer ones.


As a brief addendum to this article, please be aware that, while these kinds of gear considerations can sometimes make a difference, any focal length close up lens will serve you well, if you make the effort to shoot with vision. If you can’t have the lens you prefer, there’s no need to get caught up in gearheaded lens lust.


Roundleaf Sundew (Drosera rotundifolia) Catching and Eating A Fly


All pictures and text are © Mike Spinak, unless otherwise noted. All pictures shown are available for purchase as fine art prints, and are available for licensed stock use. Telephone: (831) 325-6917.

  • Kathy Rappaport - Mike,

    Your blog is nicely written for both the professional and amateur photographer. Very few know much about macro lenses and how they are used. While they don’t focus as fast as some lenses, I love these lenses for portraiture as well as nature photography. My first film lens 20 years ago was a Canon 50 2.5 macro lens which is no longer made but was my walk around lens. 10 years ago when I started with Digital I used it as well. Now I love the 100 2.0 Macro lens for many applications.ReplyCancel

  • naturography - Thank you, Kathy.

    The Canon 50 f/2.5 macro is no longer made? I didn’t realize that. I have one. It’s good for certain kinds of macro work (especially top-down shots of flora); I also find it’s ideal for slide reproduction, quite good for stitched panoramic landscapes, and good for portraits, too.

    I really like the 100 macro, but somehow I rarely end up using it.

    My 180 macro gets used a huge amount for macro photography, and also often for portraits. It’s a superb lens – though be warned that the autofocus is almost non-functional. That doesn’t matter to me, because I mostly manual focus , but it might matter for some portrait shooters. (It doesn’t really make a difference for extreme close up work.)ReplyCancel

  • larry angier - Hi Mike,

    Nice pix and post with good info!

    I still own my first Micro Nikkor lens purchased in the 1970s and have owned and used nearly every iteration along with the legendary 200mm Micro Nikkor lens and the current PC Micro-Nikkor lenses.

    However today, I seldom use these in the field since that is more weight and bulk to carry and manage.

    For the last 15 years or so, I’ve gone to a simpler way, the high-quality 2-element close-up diopters made my Nikon and Canon. Nikon no longer makes these slightly-small filter-like lenses, the 5T and 6T, both 62mm. Canon makes the 500D up to 77mm.

    For an on-the-go mobile photographer, these make an excellent solution for field macro work, much more convenient than tubes or carrying a dedicated macro lens.

    Though not as flat-field or perhaps as sharp as a purpose-built macro lens, seldom is this a draw back with my shooting. I use the 5T and 6T with adaptors on my 70-300mm zoom which allows me the luxury of reframing an image and good breathing room between the lens and the subject without breaking the bank.

    On my 70-200mm, not only do I get a bright and fast lens with IS/VR, but the added quality of bokah with the wide aperture. An added bonus is that with the close-up lens attached, one can also use the high-quality Nikon and Canon teleconverters for additional magnification and working distance.

    I’ve even used my 80-400mm zoom with the Canon 500D with pretty impressive results photographing wildflowers in Death Valley at greater than 1:1 magnification.

    For me, light, portable and good image quality is balanced by this approach.

    But with this approach, there are disadvantages, the lens is limited to a close-and-closer range without infinity focus, thus you can’t go for a landscape to a bugscape by simply twisting the lens, you’ve got to put it on and take it off. Problem two is that it isn’t quite as sharp as a dedicated lens, especially in the corners or on a flat and parallel subject, but seldom is nature absolutely flat and seldom is the object of our subject placed on the edges. Stopping down a couple of stops usually helps.

    Though I’ve had fun shooting my macro lenses over the years in the field, today I go light and fast and found a good solution for my style of work.

    Take care and keep your tips going!ReplyCancel

  • Kristin Bednarz | photographer - I guess I never realized there were that many macro’s out there. I purchased the 100 2.8 macro many moons ago and it works great, so that’s what I use. Now after seeing your work here on this blog and reading your wonderful description of the how and why’s involved, I’m intrigued.

    Nice work and even better, blog.

    Thanks for sharing!ReplyCancel

  • naturography - Hi, Larry,

    Thank you. I’m glad you’re liking it.

    I’ve used a lot of macro lenses, and also teleconverters and extension tubes (sometimes all three, in combination), but I haven’t yet used the close-up diopters. I’d like to; and I appreciate hearing your feedback about them.

    Dedicated lenses, extension tubes, teleconverters, diopter rings, lens reversal adapters – there are many ways to get you closer pictures. Anything that works is great.ReplyCancel

  • naturography - Thank you, Kristin.

    There are lots of macro lenses, and lots of other macro options.

    If we ever run into each other, at a DWF convention or elsewhere, I’ll be glad to show you other macro lenses, if you’d like. However, the 100 is a great choice; if it’s doing everything you want, then no need to concern yourself with other options.ReplyCancel

  • Patricia Davidson - Hi Mike, This is really great information. I am in the market for a good macro lens so this is perfect timing for me. Thanks as always for a well written and helpful post!ReplyCancel
